New Generator Controller DSE5110 Auto Start Control





The DSE5110 is an Automatic Start Control Module designed to automatically start and stop diesel and gas generating sets that include non electronic engines. The module also provides excellent engine monitoring and protection features.


The module has the ability to monitor under speed, over speed, charge failure, emergency stop, low oil pressure, high engine temperature, fail to start, fail to stop and loss of the speed sensing signal. The module displays fault conditions on the LCD display and via the LED indicators on the front.



Main Features   ·       Automatic start ·       Automatic load transfer ·       Configurable inputs ·       Configurable outputs ·       Configurable alarms & timers ·       Digital inputs ·       Analogue inputs ·       Back-lit character LCD display ·       Engine protection ·       Front panel mounting ·       PC configurable ·       100% Front panel configuration ·       LCD alarm indication ·       LED alarm indication ·       Icon based fault diagnostics     Benefits   ·       In-built engine diagnostics removes the requirement for service equipment ·       License free PC software ·       Module helps to improve the life cycle of engine starter motors

·       User-friendly set-up and button layout



Specification:

Power Supply 8 to 35 Vdc Continuous Cranking Dropouts: Able to survive 0 V for 50mS, providing supply was at least 10V before dropout and supply recovers to 5V without the need for internal batteries. Max Current Operating 320mA at 12V, 215mA at 24V; Standby 175mA at 12V, 95mA at 24V Start Relay Output: 16 Amp DC at supply voltage. Fuel Relay Output: 16 Amp DC at supply voltage. Auxiliary Relay Outputs: 5 Amp DC at supply voltage. Charge Fail / Excitation Range 0 V to 35 V Alternator Input Range: 15V(ph-N) to 300V(ph-N) 3 Phase 4wire AC (+20%) Alternator Input Frequency: 50 - 60 Hz at rated engine speed (Minimum: 15V AC Ph-N) Magnetic Pick-up Voltage Input Range: +/- 0.5 V to 70 V Peak Magnetic Input Frequency: 10,000 Hz (max) at rated engine speed Operating Temperature Range: -30 to +70C Panel Cutout: 220mm x 160mm ( 8.7” x 6.3”)
