10/100M Industrial POE Fiber Optical Switch Unmanaged 1Fiber +4RJ45 | Мобильные телефоны и аксессуары

Please Chosse the Model Number when you make the order ,Thanks



Industrial Switch

5*10/100Base-T



10/100M 5RJ45

PAC-605FE

5UTP

PAC-605FEP

4POE IEEE802.3af/at+1UTP

Input Voltage: DC10~58V (Redundant)

Operating Temperature: -30℃ ~ +75℃

Case: IP40 protection, fan-less design

Anti-static level: 8KV-15KV

MTBF: 100000 Hours



>> Description



The Ethernet switch uses store-forward architecture,fan-less and energy-saving design.The design complies with the Ethernet standard with lightning and anti-static protection. They apply to the wide range of operating temperature from -30°C to +75°C with stable and reliable performance.They can be widely applied to various broadband data transmission fields, such as intelligent transportation, Telecommunications, security, financial securities, customs, shipping, power, water conservancy and oil fields.



>> Specification



Port

RJ45

5*10/100/1000 Base-T

Power

Phoenix terminal blocks, redundant

Distance

Twisted-pair

0-100meter

Networking

Star/Bus/Tree Topology

Support

Scale

Non-limitation

Power

Input Voltage

DC10-58V

Power Consumption

<5W

Layer 2

Switching Capacity

10G

Packet Forwarding Rate

7.44Mpps

MAC Address Table

8K

Buffer

1M

Forwarding Delay

<4us

RJ45 Port

Twisted-pair, adaptive

Jumbo Frame

10K bytes

Traffic Control

Support

Mechanical Structure

Installation Method

Din-rail

LED Indicator

PWR,Link/ACT

Case

Fan-less, natural cooling

Dimension

118*91*31mm

Weight

0.36kg

Working Environment

Operating Temperature

-30℃~+75℃

Storage Temperature

-40℃~+85℃

Relative Humidity

5%~95% (non-condensing)

MTBF

100,000 Hours

Protection Level

IP Level

IP40

Power -Surge Protection

IEC 61000-4-5 Level 3 (4KV/2KV）（8/20us)

Ethernet Surge Protection

IEC 61000-4-5 Level 3 (4KV/2KV）（10/700us)

EMI

CLASS A

ESD

IEC 61000--4-2  Level 4 (8K/15K)

Free-drop

0.5meter

Anti-static

8KV-15KV
