I. FEATURES

1

Small size and light weight are suitable for work surface use and rack installation.

2

Using PWM modulation, the consumes power of crystal module is low, high efficiency, and more power.Well-designed electronic technology circuit, forced air cooling and heat treatment, with a very low temperature coefficient.

3

Low noise and low ripple.

4

Using high gain amplifier circuit design, with good fast response characteristics.

5

Using a 4-bit high sampling rate, high-resolution voltage, current digital display meter.

6

Built-in O.V.P over-voltage protection circuit and O.T.P over-temperature protection circuit, the protection function is perfect and reliable.

7

This product is designed with load terminal voltage detection terminal, which has the function of accurately reading the voltage of the load terminal and performing precise control.

8

Voltage remote compensation connector (COLRAGE SENSING), compensates for line voltage drop and improves test accuracy.

II.TECHNICAL PARAMETRIC

Name

  High efficiency factory price 0~500v 50v 100v 125v 230v 240v 460v 1a djustable switching ac dc power supply

Brand

IDEALPLUSING

Model

IPS-ATDYN4601

AC Input

Single phases 110VAC±10% or 220VAC±10% optinal

Input Voltage Range

110VAC±10% or 220VAC±10% optinal

Input frequency

50Hz/60Hz

Output voltage

0~460VDC

Output current

1A

Output Power

460W

Voltage Stabilization

≤0.3%+10mV

Load Stabilization

≤0.5%+30mV

Ripples and Noises

≤0.5%+10mVrms

Voltage Display Accuracy

3-digit Accuracy: ±1%+1 word

Display Format

0.000V-9.999V;  0.00V-99.99V;  0.0V-999.9V

Current Display Accuracy

NO current display

Output Over Voltage Protection

Built-in O.V.P. protection, protection limited value is rated +5%

Output Over Load Protection

Overload, current limit, constant current output

Over Temperature Protection

Built-in O.T.P. protection, Protection value 85℃±5% heat sink temperature

Voltage Setting

10-turn precision potentiometer

Current Setting

NO current display potentiometer

Output Polarity

Output Positive(+) negative(- ) Can be grounded at will

Heat Dissipation Way

Forced fan cooling

Work Conditions

Indoor use design,Temperature:0℃~40℃; Humidity: 10%~85%RH

Storage Conditions

Temperature:-20℃~70℃;Humidity: 10%~90%RH

Power Supply Dimension

L265*W145*H65(MM)

Packaging Carton Dimension

L450*W230*H230(MM)

Net Weight

5KG

Gross Weight

6KG

Optinal Function

#1

Desk/ tower type /19inch Rack Mount Type

#2

0-5VDC /0-10VDC analog signal control output voltage & current

#3

0-5VDC /0-10VDC analog signal to read-back output voltage & current

#4

0-5VDC /0-10VDC analog Switch signal to control output ON/OFF

#5

4-20mA analog signal control output voltage & current

#6

RS232/RS485 Communication port control by computer
