I. FEATURES

1

Small size and light weight are suitable for work surface use and rack installation.

2

Using PWM modulation, the consumes power of crystal module is low, high efficiency, and more power.Well-designed electronic technology circuit, forced air cooling and heat treatment, with a very low temperature coefficient.

3

Low noise and low ripple.

4

Using high gain amplifier circuit design, with good fast response characteristics.

5

Using a 4-bit high sampling rate, high-resolution voltage, current digital display meter.

6

Built-in O.V.P over-voltage protection circuit and O.T.P over-temperature protection circuit, the protection function is perfect and reliable.

7

This product is designed with load terminal voltage detection terminal, which has the function of accurately reading the voltage of the load terminal and performing precise control.

8

Voltage remote compensation connector (COLRAGE SENSING), compensates for line voltage drop and improves test accuracy.

II.TECHNICAL PARAMETRIC

Name

  High power adjustable ac dc 580v 600v 1a power supply with CE approved

Brand

IDEALPLUSING

Model

IPS-ATDYN5801

AC Input

Single phases 110VAC±10% or 220VAC±10% optinal

Input Voltage Range

110VAC±10% or 220VAC±10% optinal

Input frequency

50Hz/60Hz

Output voltage

0~580VDC

Output current

1A

Output Power

580W

Voltage Stabilization

≤0.3%+10mV

Load Stabilization

≤0.5%+30mV

Ripples and Noises

≤0.5%+10mVrms

Voltage Display Accuracy

3-digit Accuracy: ±1%+1 word

Display Format

0.000V-9.999V;  0.00V-99.99V;  0.0V-999.9V

Current Display Accuracy

NO current display

Output Over Voltage Protection

Built-in O.V.P. protection, protection limited value is rated +5%

Output Over Load Protection

Overload, current limit, constant current output

Over Temperature Protection

Built-in O.T.P. protection, Protection value 85℃±5% heat sink temperature

Voltage Setting

10-turn precision potentiometer

Current Setting

NO current display potentiometer

Output Polarity

Output Positive(+) negative(- ) Can be grounded at will

Heat Dissipation Way

Forced fan cooling

Work Conditions

Indoor use design,Temperature:0℃~40℃; Humidity: 10%~85%RH

Storage Conditions

Temperature:-20℃~70℃;Humidity: 10%~90%RH

Power Supply Dimension

L265*W145*H65(MM)

Packaging Carton Dimension

L450*W230*H230(MM)

Net Weight

5KG

Gross Weight

6KG

Optinal Function

#1

Desk/ tower type /19inch Rack Mount Type

#2

0-5VDC /0-10VDC analog signal control output voltage & current

#3

0-5VDC /0-10VDC analog signal to read-back output voltage & current

#4

0-5VDC /0-10VDC analog Switch signal to control output ON/OFF

#5

4-20mA analog signal control output voltage & current

#6

RS232/RS485 Communication port control by computer
