MQ QS Sabvoton SVMC72150 150A 3000W-4000W BLDC Sine Wave Three Speed Electric Bicycle Motor Controller With 48V-144V N2 Display |

MQ QS Sabvoton SVMC72150 150A 3000W-4000W BLDC Sine Wave Three Speed Electric Bicycle Motor Controller With 48V-144V N2 Display |

1) FOC sine-wave controller applied to BLDC or PMSM

2) The controller match one motor to get best electric angle no more than 3 minutes for the first time.

3) minimizing the torque pulsation, achieving non-noise, on-vibration run with great Comfort

4) The precise current ring can provide accurate torque input to meet the requirement 0f large torque output during vehicle starting and climbing.

5) work efficiently, reducing the heat consumption and extending the mileage

6) built-in protection: block protection, over-current protection, over-heat protection, over-voltage protection and so on, guaranteeing the system and driver safety

7) status and fault intelligence management provide the information including the run-mode, fault type and so on, LED also twinkle in different way to indicate the fault type, all these make the diagnosis and repair easily

8) convenient external interface: reversing, cruise, ebs and so on

9) parameters and functions can be configurable by computer or mobile phone

10) CAN bus is optional for meter or BMS application
