4G/3G LTE Industrial Wireless WiFi Router 2.4Hz 300M W/SIM Card Slot EC25-EUX Mini PCIe Modem Global Version VPN VPDN PPTP L2TP |

Specification of Quectel EC25-EUX  Mini PCIe:



Introduction of 4G LTE Industrial Wireless Router with Built-in EG25-G for Global V519-industrial 3G/4G router-adopts high performance 32-bit processor, high speed process protocol and large data, equipped with multiply 3G/4G industrial modules(WCDMA/EVDO/TD-SCDMA/FDD-LTE/TDD-LTE), provides 10/100M adaptive ethernet port, WiFi wireless port, serial port, integrated with multiply terminal devices,easy to do configuration via WEB and remote control. Features of 4G LTE Industrial Wireless Router with Built-in EG25-G for Global 1 Wide Voltage Input DC7V-35V With Auto Power-Off Protection; 2 Site Control, Port Mapping, DMZ Host etc.; 3 IEEE 802.11 b/gn, Max. Transmission Rate: 300Mbps; 4 Wireless Video Surveillance and Dynamic Image Transmission Supported; 5 CDMA, WCDMA, GSM, TD-SCDMA, EVDO, TDD-LTE, FDD-LTE etc. Supported; 6 Serial Port, TCP/UDP Pass-Through Data Transmission and AT Command Interactive Transmission; 7 Cloud Control, Auto Upgrade Supported; 8 VPN, VPDN, PPTP Client, L2TP Client Supported 9 Auto Network Detection, Dial Failure Auto Reboot, Timing Reboot etc. Supported; 10 Wired Connection, 4G Network Backup, Auto Switch Between Wired Connection & 4G Network; 11 Hardware & Software Watchdog Crashproof Design, Running Stably; Parameters of WiFi Basics

Max. Transmission Rate: 300Mbps

Working Band: 2.4GHz

Wireless Mode(Option): 11b/g/n/, 11bg mixed , 11bam mixed (Def)

Wireless Mode(Option): 11a/n on1y  11an mixed(Def)

SSID Broadcast Switch Supported

Quantity of Users

30x WiFi Users Connected Simultaneously Supported

200x Users via Ethernet Cable Connected Simultaneously Supported

Safety Parameters

Support WPA(Individual)/WPA2(Individual)/WPA-Mixed(Individual)

Support TKIP/AES/Auto Encryption Algorithm

Transmission Distance Outdoor Without Barriers Up to 200 Meters Parameters of System GPU Industrial High Performance Embedded MIPS CPU, main frequency 580Mhz MMU With MMU memory management unit built-in CPU, it can prevent system abnormality caused by memory spilling. FLASH 128 Mbits, have enough memory to store program and data DDR2 1024 Mbits, have enough cache to improve arithmetic speed of system Parameters of Interfaces WAN 1x 10/100M adaptive WAN port, isolation built-in, auto flip supported (Auto, MDI, MDIX), PPOE supported Serial Port RS232 Indicators 4x Indicators Antenna Port 3x Antenna Ports, Standard SMA Antenna Port USIM Slot 1x SIM Slot Power Port Standard DC connector Parameters of Power Input Voltage Wide voltage designed, DC7-35V, adapter can power it on directly and it has buit-in power reverse and over-voltage/current protection. Adapter DC12V 1.5A Communication Current <300mA Standby Current <150mA Other Parameters Case Adopt metal case, anti-radiation/interference, safe isolation between case and system, lightningproof, applicable for serious conditions. Outline Dimension 82mm*82mm*24mm(3.2in*3.2in*0.9in) Package Dimension 250mm*170mm*75mm(9.8in*6.7in*2.9in) Weight 394g(0.87lb, 13.9oz) Operation Temperature -40°C~+85°C(-40°F~+185°F) Storage Temperature -50°C~+95°C(-58°F~+203°F) Humidity 95% (Non-Condensing) Typical Application(WiFi Covered Application) Finance Center monitoring, mobile stock transaction and info inquiry; Communication Power environment monitoring, electric circuit information inquiry; Traffic GPRS, SMS, GPS vehicle monitoring and dispatch, banknote transport monitoring, school bus monitorning; Power Power system realtime dynamic monitoring and auto compensation; Heat Heating system real-time monitoring and maintenance; Police

Vehicles of police station, 911 and traffic police monitoring and dispatch

Security mobile data inquiry like(ID verification, wanted, child lost information etc.),

Mobile traffic communication data inquiry like licence plate etc.;

Work Site Mobile work management, other outdoor staff mobile data inquiry; Weather Data collection & transmission Charge Charging station monitoring & management, data transmission; Water Resource Quantity of water monitoring and transmission; Life Real-time gas data colection and automatic control, water station real-time monitoring and maintenance; Scenic Area WiFi covered, wireless network ads pushing and devices management; Hotel WiFi covered, wireless network ads pushing and device management; Models Comparison



Package Contents 1x 4G Industrial Wireless Router 1x 4G Antenna 2x WiFi Antenna 1x Power Adapter 1x User Manual
