Cheap Mini 4 Axis 1.5kw 2.2kw Water Cooling Spindle Motor 6040 6090 6012 1212 Mach3 USB Port CNC Router |

Cheap Mini 4 Axis 1.5kw 2.2kw Water Cooling Spindle Motor 6040 6090 6012 1212 Mach3 USB Port CNC Router |

Unavailable in

Product  Features

Attention Please!!

All LINTCNC products can be custom­er made to suit your requirements. Please confirm which working area of cnc router suitable for you . Moreover, now this product is in good promotion.

Welcome to Contact Rachel Zheng directly to get a discount !!!

Cast -iron structure

Cast-iron table

Hiwin linear square guide rail

Taiwan original TBI ball screw

1.5 KW water cooling spindle

ET inverter

86BYG-450B Stepper Motors and MA860 Leadshine drivers

NC studio control system

Pls attention:  If you buy the machine, the following accessories will be given for free

(thermometer,light,blow gun,voltmeter).

Parameters

PS:All the working area and specifications can be customized according to your requests.

Model

LT-4040 /LT-6060 etc.

Effective working area

400*400*200mm

Machine body structure

Cast-iron structure

Table style

Cast-iron T-slot table

Guide rail

Hiwin linear square guide rail (HGR20)

Driving method

Taiwan original TBI ball screw

Spindle

1.5 KW water cooling spindle (ER16)

Spindle speed

0-24000rpm

Inverter

ET inverter

Motors and drivers

86BYG-450B Stepper motors and MA860 Leadshine drivers

Control system

NC studio control system

Working accuracy

<0.03/300mm

Working speed

<7000mm/min

Traveling speed

0-7000mm/min

Instruction format

G code *.u00 *.mmg *.plt

Working voltage

AC220V, Single phase, 50-60Hz

Standard software

Artcam 2010

Compatible software

Type3/Castmate/Coreldraw/AutoCAD or other CAM/CAD software

Environment temperature

0-45℃

Environment humidity

30%-75% No coagulate water

Tool sensor

Yes

Others

  English manual, Tool box, Tool sensor, etc.

Optioanl parts

Mach3 USB control system

2.2KW Water cooling spindle(ER20)

Water tank & water mist cooling system

4th axis for engraving round materials ( Rotary Axis)

Application

Furniture Industry:Wave Plate, fine pattern, antique furniture, wooden door, screen, craft sash,composite gates, cupboard doors, interior doors, sofa legs, headboards and so on.

Advertising Industry:advertising identification, sigh making, Acrylic engraving and cutting, crystal word making,blaster molding, and other advertising materials derivatives making.

Mold Industry:A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand,plastic sheeting, PVC pipe, wooden planks and other non-metallic mold.

PS: For the sample processing process, please view the test video at the top.

Packaging Improving

Three layers---

2. If shipping by FCL, then it can be wrapped with wrapping film withour wooden boxes, it can loading in our factory directly.

Parameters Warranty (Our service)

1.Guarantee: 3 years guarantee of the whole machine & 1.5 years warranty for motors and spindles

2.Software issue: Supply technical support for machine lifetime free.

3.Hardware issue: Main parts(excluding the consumables) shall be replaced/ repaired free of charge if there is any problem during the warranty period.

4.Support online: our engineer give 1 hours to solve question online.

5.Training in LINTCNC factory: We are able to train your staff after placed order in our factory for free.
6.Oversea service: We are able to send technician to your workshop to do the installation and training. You will need bear the related costs. (flight,visa,hotel,training costs, etc.)

Customer Feedback

Please click and view the feedback video from our customers.
