Introduction:

KO-SC403 is an access control devices produced by Software, which is made with elegant design and professional surface treatment. The device have lock control, alarm, exit button, door sensor. The wiegand-in interface is used to connect external reader to construct master and slave system. Also the device can be used to connect with a control panel as a reader by wiegand-out interface. The operation can be done on the device through LCD display, also can be done on PC software and upload to the device through TCP/IP, RS232/485 communication. The USB-host is used for data download and upload, including user template and record etc. KO-SC403 is suitable for house, small office and factory etc

Features:

Tough casing design

Easy installation, safe and reliable

Simple and convenient operation method

ID card standard, MF card optional

Full door lock control system

Wiegand out to connect with control panel

Wiegand in to construct master and slave system

Audio prompt and LED feedback guide the user to operate

Specifications:

ID card Capacity

30000

Transaction Capacity

50000

Communication

TCP/IP, RS232/485, USB-Host

Access Control Interface for

3rdparty electric lock, door sensor, exit button, alarm, Door Bell

Wiegand Signal

Output&Input

Standard Functions

Anti-passback, SMS

Optional Functions

Workcode, Webserver

Display

LCD

Power Supply

12V DC

Operating Temperature

0 - 45

Operating Humidity

20%-80%

Dimension(L*W*H)mm

129.5X95X48.5

Gross Weight

1.5KG
