Flexible LED screen panel module Indoor 320*160mm P1.88 P2 P2.5 P3.076 P4 RGB Full color Soft LED display panel module

Overview

The Flexible Display Module Series Are 240mmx120mm / 256mmx128mm / 320mmx160mm;And The Point Spacing Includes：P1.25 / P1.29 / P1.56 / P1.579 / P1.66 / P1.875 / P1.88 / P2 / P2.5 / P2.58 / P3 / P3.076 / P4 .

Packing list

1 pcs full color led module

1 pcs flat ribbon data cable

1 pcs power cable（if you buy N pcs，we will supply N/2 pcs power cable ，because 1 pcs power cable support 2 modules）

Features

1.The module standard size design is 320mmx160mm, low current, low heat, high contrast 5000:1, high brightness and high gray level, refresh ≥ 1920hz, 12-16bit gray level, and the image shows no delay and no dragging;

2.The minimum bendable diameter is up to 509mm, and the visual angle is up to 160 °. It is suitable for curved surface flexible display such as stage background, exhibition hall and indoor conference room, which helps to improve the environmental grade and create a special visual atmosphere;

3.The module is installed with strong magnetic adsorption, which can be slightly adjusted, and the flatness of the screen is good. Front maintenance design of power board, special scenarios, can realize front installation, and can meet front maintenance with specific tools;

4.PCB board adopts flexible board, and the mask/bottom shell adopts superior silica gel material;

5.The module is only 5.3mm thick, with ultra-thin design and small space occupation;

Process Introduction

1.PCB board adopts Gold Sinking Process, S1000-2 base material, special circuit layout, multi-layer board process design, and high-level materials to greatly reduce the phenomenon of "color temperature";

2.The whole series adopts high contrast black light. When the screen is black, the ink color and luminous angle of the whole screen are consistent. When playing HD video, the screen is fine and soft with good visual effect.

3.The bottom shell is made of top-grade silica gel raw materials, with good flexibility, high temperature resistance, low temperature resistance, electrostatic elimination and strong protection performance;

4.The PCB board is welded with copper column and adhesive backing to form a lockable base with the bottom shell, making the module more firm and reliable;

5.The single board is equipped with 18 strong magnetic magnets, with a single magnetic content of 2000GS, which greatly solves the problem of degumming and warping of ordinary modules, and effectively improves the flatness and use effect of the screen.
