New 3NH NH 310 High Quality Portable Colorimeter 8mm Diameter /4mm Diameter Color Meter Tester

Description

1.Introduction:

High-End Brand of Domestic Colorimeter

NH310 is a mainstream brand colorimeter introduced by 3nh which has synthesized the advantages of ten more traditional imported colorimetersand has experienced ten thousands tests and applied many innovative technologies. Accurate, Stable, Exquisite and Affordable!

The Preferred Solution for Color Quality Control Management

NH310 high-quality portable colorimeter has adopted multi-channel color sensors of international brands, more stable IC platform as well as efficient and accurate algorithms to provide users with accurate and fast color management and application. NH310 is also designed with ergonomics and humanized operation and it has applied for a number of patents. NH310 is a multifunctional colorimeter with high quality and competitive price. 3nh insists on independent research whose technology innovation is unique in color management field. NH310 is the most convenient colorimeter for users.

1. Leading Humanity Design and Convenient Operation Auto White and Black Calibration at Startup Structure Design in line with Ergonomics Easy-to-use Operation Interface 2. Stable Measurement Performance The average fluctuation of E is less than 0.06, actually more in 0.03~0.06. Portable structure design which is more conductive to keeping the instrument stable when using. 3. Flexible and Accurate Locating Camera locating can solve the problem of locating a small area. The minimum width of locating is 4mm. Illumination locating is a fast, simple and convenient locating function which is the original function by 3nh. 4. More Measurement Modes Three measuring apertures for more circumstances. Five color spaces for more color schemes selection. Three light sources for more circumstances. 5. PC Software—Realize More Function Expansion 3nh has the intellectual property of PC software. The corresponding software serial number and password protection are configured in 3nh colorimeter. Be able to?perform color difference analysis, color difference cumulative analysis, chromaticity index, color sample database management, simulating object color, etc. 6. Advanced Power Management Design 3nh is the first enterprise using high capacity Li-ion battery in colorimeter. 3nh Li-ion battery can be repeatedly charged which will save cost. Meanwhile, it can measure more than 3000 times on one charge to ensure the stability of long time measurement.

National Patent and Innovative Technology

No.1 Camera locating and illumination location (NH310 has new functions of double locating.)

No. 2 Built-in white plate; Automatic calibration at startup (for NH310)

No. 3 Extended aperture (optional), available for measuring concave surface

Specifications of NH310 Colorimeter

Model NH310 Display Mode/Color Space CIE L*a*b; CIE XYZ; CIE RGB;CIEL*u*v; CIE*C*H; Whiteness &Yellowness; Color Fastness Color Difference Formula E*ab; L*ab; E*C*H; ECIE94; EHunter Illuminating/viewing geometry   8/d (8°illumination angle/diffuse viewing) Light Source LED blue light excitation Detector Silicon photoelectric diode Measuring Aperture 8mm Diameter; 4mm Diameter; 8mm Diameter extended aperture (optional) Measuring Conditions Observer: CIE 10° Standard Observer  Illuminant: CIE Standard Illuminant D65; D50; A Measuring Range L: 0 to 100 Repeatability   Standard deviation within E*ab 0.06   (Measurement Conditions: Average of 30 measurements of standard white plate) Minimum Interval Between Measurement Approx. 1 sec Battery Life More than 3000 measurements Lamp Life more than 1.6 million times in 5 years Display TFT True-color; 2.8 inch@(16:9) Interface Model B: USB   RS-232: Baud rate 19200bps Operating Temperature Range -10 to 40 Celsius Storage Temperature -20 to 50 Celsius Humidity Range       less than 85% relative humidity, no condensation  Weight 500g Dimensions 205 x 70 x 100 mm Size of the Packing 435 x 205 x 345mm Standard Accessories AC Adapter; Li-ion Battery; Operation Manual; Software CD; USB Cable; White Calibration Cover; Φ8mm and Φ4mm Measuring Aperture Optional Accessories extended aperture(8mm Diameter); Mini-printer; Printer Cable; Powder Test Box; Universal Test Components
