Switching Power Supply 600w 27V 110 or 220VAC Single Output Input 600W 22.2A for Cnc Led Light |

Brand NameCHUXModel NumberS-600W-27Vis_customizedYesOutput Power>500WOutput TypesingleOutput Frequency47~63HZMeasurement unitpiece/piecesEach pack1OEMyessize 238X124X65mmcertificateCE ROHSoutput voltage27VDCadjustableyeswalt600WDC adjust10%Output Current22.2AOutput Voltage27V

Unavailable in

Description

WELCOME TO OUR SHOP!

switching power supply 600w 27V 110 or 220VAC single output input 600W  22.2A for cnc  led light (S-600W-27V) free shipping

Features:
High efficiency, high reliability and low cost
Switch input voltage range choice
100% full load and machine test
Protection characteristics: short circuit/overload
Air cooling

Specificate:

Size:  238X124X65mm

 WALT:  600W

output voltage :27v

Products show











Model

Specification

  S-600-5   S-600-12   S-600-15   S-600-24   S-600-48   DC Output voltage   5V   12V   15V   24V   48V   Output voltage range(Note:2)   ±2%   ±1%   ±1%   ±1%   ±1%   Rated output current   80A   50A   40A   25A   12.5A   Output current range   0~80A   0~50A   0~40A   0~25A   0~12.5A   Wave and noise(Note:3)   75mVp-p   120mVp-p   150mVp-p   240mVp-p   240mVp-p   Inlet stability(Note:4)   ±0.5%   ±1%   ±1%   ±1%   ±1%   Load stability(Note:5)   ±1%   ±0.5%   ±0.5%   ±0.5%   ±0.5%   DC output power   400W   600W   600W   600W   600W   Efficiency   80%   83%   84%   86%   87%   Adjustable range for DC voltage   ±10%   ±10%   ±10%   ±10%   ±10%   AC input voltage range       100~132VAC/190~240VAC 47~63Hz,250~340VDC   Input current       5A/230V   Power factor       0.65 - 0.75   AC Inrush current       46A/230V   Leakage current       <3.5mA/240VAC   Overload protection       120%-150% Reset: auto recovery   Over-voltage protection       120%-150%   High-temperature protection       ERH3≥65°C~70°CFan on, ≤55°C~60°CFan off, ≥80°C~85°C, Cut off output (5-15V)~(24-48V)   Temperature coefficient       ±0.03%/°C(0~50°C)   Setup, rise, hold up time       1s, 100ms, 50ms   Vibration       10~500Hz, 2G 10min,/1 cycle. Period for 60min, Each axes   Withstand voltage       I/P-O/P:1.5KVAC  I/P-FG:1.5KVAC  O/P-FG:0.5KVAC   Isolation resistance       I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC   Working temperature and humidity       -10°C~+60°C, 10%~95%RH   Store temperature and humidity       -20°C~+85°C, 10%~95%RH   Overall dimension       238X124X65mm (L*W*H)   Weight       1.23Kgs   Safety standards       GB4949,UL60950,EN60950   EMC standards       According to GB9254 EN55022 EN55024 A level design
