1.Feature

Ultra Low Illumination 1/2.8" CMOS Sensor+HI3516C

2.0 Megapixel 1920*1080 Resolution

Dual H.264 Stream, resolution, frame rate, bit rate adjustable

Support IE, Firefox, Google browser

Support iphone, Android smart phone

HD 1.0MP 1080P

Support Day/Night

Waterproof Enclosure, indoor / outdoor Use

Metal Material

2.Specification

Model

1080P

Sensor

1/2.8"CMOS

System Structure

Embedded RTOS,dual-core 32bit DSP,pure hard compression ,watch dog

DSP

HI3516C

Minimum Illumination

Color : 0.01Lux

Blank & White:0.001Lux@(F1.2,AGC ON),0Lux with IR

Video Compression

H.264,support dual-stream,AVI;0.1M~8Mpbs variable;1~30f/s variable;

Image output

main stream: 1920*1080,1280*720;sub-stream:704*576;

features

Support WEB,OSD,live video transmission,motion detect and IO alarm,front-end storage/playback/download, and center reminder and image linkage,

support JPEG capture;united remote client monitoring software,MYEYE;perfect SDK;

Network
connection

1 RJ45, 10/100M Ethernet adaptive interface;

 support RTSP / FTP / PPPOE / DHCP / DDNS / NTP / UPnP network protocols;

ONVIF

Support

Mobile
monitoring

Support mobile monitoring(iPhone,Android)

Lens

1080P 2MP Default 3.6MM ( Other Lens is Optional )

IR LED

3pcs Array LED

IR Distance

25M

Power

DC12V,3W(consumption),6W When IR LED On

Notes

Power supply is not included

3.Packing Contents

1*1080p IP Camera

1* CD

Power Supply is not included !!

Bracket is not included!

FAQ

1.Q:What’s the default ip address of the camera ?

   F: 192.168.1.10 Username : admin  Password : null ( empty ) !

2.Q: Does the camera supports Motion Detect,FTP,Email alarm, RTSP and so on ?

   F: Yes ! All the IP Cameras we are selling supports these functions .

  1) Please Setup the motion detection in the CMS software .

  2) We suggest the Sever-U and FileZilla FTP Server to upload the video or image.

  3) For the Email alarm,please use Email server which supports SMTP ( Hotmail ,Yahoo not support SMTP ,it not supports Gmail temperately since the server problem ) .

  4) ,RTSP URL for VLC media Player :

  rtsp://$(IP):$(PORT)/user=$(USER)&password=$(PWD)&channel=$(Channel)&stream=$(Stream).sdp?real_stream

  Example : rtsp://10.6.10.25:554/user=admin&password=&channel=1&stream=0.sdp?real_stream

3.Q: What’re the ports information of the cameras ?

   F: ONVIF 2.0 Port 8899 ;RTSP Port 554 ;HTTP Port 80;Media Port 34567

4.Q:Does the camera support IE ,Chrome ,Firefox and so on ?

   F: Since the plug-in problem ,for website interface IP address URL,ONLY IE supports Multi Language . Chrome,Safari just support Chinese .

   For cloud server XMEYE.NET ,it supports multi language

5.Q:When I finish the steps to add the camera to the CMS list,why it notify"Can’t find the Device"even I can see the default ip address 192.168.1.10 in the menu .

   F: It is the IP Address conflict ,the default ip address is not in the same network segment as your router.

   Please click"Edit Device"to change the camera’s ip address to make them in the same network segment !

   For example ,if your router’s ip address is 192.168.0.1 ,then you need to change the camera’s ip address to 192.168.0.XX .
