iBeacon / beacons ble Enhanced customization for Logo beacon |

iBeacon / beacons ble Enhanced customization for Logo beacon |

1 year life battery CR2477 and Colorful Case!

Customized Logo with Free Laser Printing !

1.8 types of Ibeacon hardware with different case and batteries;

2.Able to customize a case with low cost easily and rapidly;
3.Document are provided to change UUID, Major, Minor and other parameters;
4.iBeacon with Build-in Firmware and also can upload for customers before delivery;
5.Ibeacon Based on TICC2541 bluetooth low energy module and battery CR2477;
6.Ibeacon Support IOS7.0 and Android 4.3 or above;
7.Ibeacon effected range us 30m and Max Range is 100m;
8.All types are with CC/CE/RoHS Certified;

Item

Value

Remarks

Firmware

iBeacon

Version 2.1.1

Battery model

CR2477 3pcs

Coin battery, 3.0Vdc, 1 pc

Operation Frequency

2400-2483.5MHz

Programmable

Frequency Error

+/- 20KHz

Modulation

Q-QPSK

Standby current

100uA

Depends on duty cycle/broadcasting frequency

Broadcasting Frequency

900mS

Duty cycle

Output Power

0 dBm

Default setting, programmable

Receiving Sensitivity

-93dBm

High gain mode

Transmission distance

50 meters -100meters

BER<0.1%, Open space

Antenna

50ohm

On board/ PCB Antenna

Size

83mm*58mm*33mm

Operation Voltage

2.0-3.6V

DC

1.Can be able to customize the case with your logo and the color you prefer with free cost according to the qty;

2.Package case can be customized if required;

3.Pre-configure the value of parameter before the shipment;

4.SDK is available to help customers build their own APP ;

5. Free laser print service is provided according to the qty;

6.We have professional Engineer to provide advices if need.

ibeacon modules freeshipping ble4.0 watch beacon

 Please feel free to add my skype for open and convenient talk !

Technical parameter setting:

2.1  Use Platform

        Receiving end (mobile) hardware must be Bluetooth 4.0 or more, the software requires Android 4.3 or

 above Apple IOS5.0 more.

2.2  Test Software

       Software Name: Light blue, the software can be downloaded free from the Apple APP store.

2.3  Light blue menu Introduction             Open the software Light blue, this time will automatically search out iBeacon device can also be connected to

 the sliding screen refresh Equipment, open software displays the following figure, this time in the menu Perie

herals Nearby displayed at WGX ibeacon It means that the search has been successful to the device, the device

name is WELLCORE factory default  settings, the user can modify Refer to Section 2.9 to modify the method.

2.4  The login password and how to modify.

2.5  UUID revise

2.6  Major revise

2.7  Minor revise

2.8  Measured Power revise

2.9  Device name revise

2.10 Transmit Power revise

2.11 Broadcast frequency revise

2.12 Reset factory settings

3.1  Test Software

Attract customers, and increase the possibility of shopping.

Increase the interaction with the customer through a unique mobile app, with personalized service notifications, promotions,

coupons, and high value-added functions.

Influence purchases through targeted promotions and campaigns for customer retention.

Describe paintings, art objects, to give more details to the museum or exhibition visitors, improving their experience.

Allow interaction with visitors in a museum, creating pathways of augmented reality.

Advertise and offer services to customers. (discount, coupons, tickets, etc. ..)

The mobile marketing platform for wellcore Beacon, helps the retail world to interact with their customers, offering targeted

purchases.

Through mobile devices, it is possible to engage and enhance the user experience, both for the world of retail and for museu

m environments, in order to let them enjoy a unique experience.

1. What is a beacon?

A beacon is a small wireless device that constantly broadcasts radio signals to nearby smart phones and tablets.

Think of it as a lighthouse emitting light in regular intervals. Mobile apps can listen for that signal,and, when they receive it,

trigger a location-based action.

2. Why is Bluetooth low energy (BLE) important?

BLE is the signal emitted by beacons, and it's important for two reasons.

First, it transmits radio waves, which can penetrate physical barriers like walls, unlike Wi-Fi or cell signals, which are often

disrupted.

Second, BLE consumes only a fraction of the battery power that classic Bluetooth does.

3.How’s the quality and price of WELLCORE beacons ?

Wellcore is a professional ibeacon manufacture in China and holds its own factory and with engineers to offer Consulting and

 advice, the quality is very reliable and price is factory direct sale price. Beacon warranty is 12months and if any one get fault

when recieved, we will repair or change new ones to customers, also we will offer very excellent discount in future orders.

4. Do WELLCORE beacons Certified ?

Yes, all Wellcore beacons are with FCC/CE/RoHS Certification, we can provide to customers anytime if need.

 5. Do WELLCORE beacons work with i-P-h-o-n-es and Android phones?

Yes, Wellcore beacons work with iOS 7 and ios 8 and Android 4.0 or above.

6.How can I configure the beacons if I bought samples ?

Wellcore will provide document for customers to configure the beacons, also will provide apps for testing, sdk for developing

 apps,and with videos to show clearly all steps of configuration.

7.How many beacons types can WELLCORE provide so far ?

Wellcore is providing 8 types of beacons, some are normal beacons, some are solar cell beacons, some are waterproof beac

ons,some are sticker beacons.

 8. Can Wellcore custom beacons ?

Yes, Wellcore is able to customize beacons with special functions, the case, PCBs, Colors , of beacons according to customers’

 requirements quickly with low cost.

7*24 online EMAIL and TradeManager service!

1. We are China Leading ibeacon Manufacturer.

2. Own a big factory and quality control apartment.

3. Alibaba Assessed 3 years Gold Supplier.

4. All products are CE FCC RoHS certificated.

5. 100% QC inspection Before Shipment.

6. Best Quality & Best Service with Competitive price.

Our company has established a new product development center to meet the requirements of our OEM clients. By offering the best quality products, competitive prices and excellent services, we are always prepared to meet any requirements from our customers all over the world regardless of the different standards of each country.

With professional manufacturing processes and perfect quality control system, our products enjoy a high reputation in US and overseas. We can give clients the best prices for a larger profit margin. Potential customers are welcome to contact us or visit our factory for more details.

  Wellcore Technology Co.,Ltd

  Contact : Abby Zou

  Skype:+86 18702502707

  TM: cn1000994341

  Tel:+86-755-83756136-602

If have interests in our products, Please click "Order" Now!

Notice: only white color is avaible now, if the white sample test well. we will customize other colors for you in future order.
