The original design, harmoniously complementing the appearance of the car.

Materials and Components of high quality-Toughened aluminum profile with protective-decorative anode coating, and ABS plastic with protective layer, preventing burning out and discoloration.

Aluminum profile rails have trademark engravingAnd two kinds of coating:

1. anode Gray.Is a colorless anodized-oxide high-strength coating. This is the most reliable way to protect aluminum and its alloys from corrosion and other aggressive environmental impacts. The electrolytic-derived oxide layer has a density of hundreds of times the density of the natural oxide film. In comparison with other ways of coating (dyeing, varnishing, coating with polymeric films, etc.), anodizing excludes the problem of subfilm corrosion and separation. This coating has high decorative and operational properties. Due to the transparency of the anode film, the profile has a natural metal color. Before the coating, the profile is subjected to special processing, which creates a velvety surface sparkling in the sun.

2. polymer black.This kind of aluminum profile coating is double layer.

The first layer of the base is colorless, anodized-oxide coating. Is a conversion layer that reliably protects the aluminum profile, sealing it from all sides. This is the most reliable way to protect aluminum and its alloys from corrosion and other aggressive environmental impacts. Can be used as an independent finish coating of silver color, and be an excellent basis for applying subsequent layers of coating.

The second layer is a polymer coating of black color. It is applied by electrostatic method and is baked at high temperature directly on the product. Is a reliable decorative layer. Has a matte saturated-black velvety surface.

Installation method-Mounting in regular places in the car body (located under the plugs in the roof drains) with a screw connection, without gluing to the roof surface.

Load capacity-80 kg., In accordance with the recommended vehicle manufacturer, the maximum permissible load on the car roof.

Static carrying capacity of rails is not less than 100 kg. High load capacity is provided by the rigidity of the metal structure of rails. However, the recommended load of 80 kg is selected taking into account the following parameters:

1. vehicle body (roof) handling according to the manufacturer's technical requirements.

2. Strength of the fastening elements installed in the car body.

3. inertial and aerodynamic forces arising from the movement of the vehicle with the cargo placed, and significantly increasing the load on the structure.

Recommendations when using rails as a trunk (subject to the installation of cross-sections):

1. small and heavy cargo place as close to the rails as possible.

2. when placing several cargoes on rails at the same time, distribute them evenly over the cross surface. And heavier things need to be placed closer to the rails, and lighter to the center.

3. securely fix the cargo to the transverse and the rails themselves.

4. Additionally fix the drop ends of the long cargoes to the car body, to exclude their rocking during the transport process.

5. choose the most optimal mode of movement with reduced speed, avoiding sharp overclocking and braking.

Reyng-1755 mm.

Cross-mounting-Screw connection in the longitudinal groove of the aluminum railing profile.

Width of transverse installation-Floating, fixing cross sections is possible anywhere in the aluminum railing profile, maximum width1325mm.

Dimensions of the green.

Categorically prohibited:Independently finalize, complete or repair the purchased goods, as this results in loss of consumer and operational properties of the goods, as well as loss of warranty.
